경관조명

홈으로 경관조명 투광등

DF-22-1

LAMP	POWER LED 120W
BODY	ALUMINIUM DIE-CASTING
COVER	TEMPERED GLASS
BRACKET	ANGLE CONTROL
LENS	5, 8, 15, 30, 45, 60
COLOR TEMPERATURE	3000K / 4000K / 5700K / R.G.B.W
SIZE	L214 * W214 * H322
INPUT	DC 24V
PSU	ON OFF or DMX512
FINISH	POWDER COATING
PROTECTION	IP65

DF-22-2

LAMP	POWER LED 72W
BODY	ALUMINUM DIE-CASTING
COVER	TEMPERED GLASS
BRACKET	ANGLE CONTROL
LENS	5, 8, 15 , 30, 45, 60
COLOR TEMPERATURE	3000K / 4000K / 5700K / R.G.B.W
SIZE	L195 * W195 * H270.5
INPUT	DC 24V
PSU	ON OFF or DMX512
FINISH	POWDER COATING
PROTECTION	IP65

DF-22-3

LAMP	POWER LED 48W
BODY	ALUMINUM DIE-CASTING
COVER	TEMPERED GLASS
BRACKET	ANGLE CONTROL
LENS	5, 8, 15, 30, 45, 60
COLOR TEMPERATURE	3000K / 4000K / 5700K / R.G.B.W
SIZE	L170 * W170 * H224
INPUT	DC 24V
PSU	ON OFF or DMX 512
FINISH	POWDER COATING
PROTECTION	IP65

DF-22-4

LAMP	POWER LED 32W
BODY	ALUMINUM DIE-CASTING
COVER	TEMPERED GLASS
BRACKET	ANGLE CONTROL
LENS	5, 8, 15, 30, 45, 60
COLOR TEMPERATURE	3000K / 4000K / 5700K / R.G.B.W
SIZE	L134 * W134 * H208
INPUT	DC 24V
PSU	ON OFF or DMX512
FINISH	POWDER COATING
PROTECTION	IP65

DF-22-5

LAMP	POWER LED 18W
BODY	ALUMINUM DIE-CASTING
COVER	TEMPERED GLASS
BRACKET	ANGLE CONTROL
LENS	5, 8, 15, 30, 45, 60
COLOR TEMPERATURE	3000K / 4000K / 5700K / R.G.B.W
SIZE	L96 * W96 * H181
INPUT	DC 24V
PSU	ON OFF or DMX 512
FINISH	POWDER COATING
PROTECTION	IP65

PRODUCT DRAWING
